CNC Punching machine(VT)

公司介绍

 VT series are modified to meet Chinese market on the basis of RT series. Plain and economic, it can be regarded as the elite of RT series. With German numerical hydraulic system, its punching speed can reach 600 times per minute and 350 times per minute at 25mm pace.

* Similar to RT series, it features O-type closed body, inlay turret, integrated beam, high precision wormwheel and worm auto-index, brush and ball mixed worktable. In addition, the control system, large lead ballscrew, linear guide, pneumatic, hydraulic and electric components are made by world famous manufacturers, thus ensuring the reliability of the whole unit. What is more, it is equipped with float pneumatic clamp with large holding force and stable feeding characteristics. The integrated swallowtail type carriage is high in rigidity. The clamp is easy to move.
