The RT series CNC turret punching machine with international advanced technology is produced in cooperation with Switzerland RASKIN.

* It is equipped with hydraulic system manufactured in Germany, numerical proportionate servo valve. Full loop control, good dynamic and static response characteristics. High resolution, low hysteresis. No middle dead zone. Resistance to temperature variation and interference. Punching speed up 1000 times per minute. Punching speed up to 390 times per minute at 25mm pace.

* The turret adopts the specialized fixture for pair processing, ensuring the coaxiality of the upper and lower dies, which can extend their service life greatly. The inlay structure simplifies the structure of the turret, which also helps to extend its service life.

* The pneumatic, hydraulic and electric components are all famous brand products like Festo, Schneider, SMC, SMB and Turck, thus ensuring the reliability of the whole unit.

* The pressure adjustable hydraulic clamp is used to hold materials of different nature and thickness at different press, thus ensuring that the plates can be held tightly while leaving no dent on the soft and thin plates.

* The vacuum waste collector is installed to ensure that waste can drop through the waste hole during high speed cutting, eliminating waste rebounding, which can extend the service life of the die.

* The worktable with hard brush and ball is wide enough to reduce the noise and vibration when the machine is running, and protect the plates from getting scratched.

* The large lead ball screw and linear guide from Japan THK, NSK, NTN, German Bosch Rexroth and INA are used to ensure processing accuracy.

* The O-type body welded with steel plate has gone through second aging treatment to eliminate stress to a large extent.

* The imported die ensures long service life.

* The CNC system has clamp self protection function, which can ensure that the protected area is not punched to avoid damaging the die and clamp.

* The auto-index adopts high precision wormwheel and worm mechanism. The maximum die diameter can reach 88.9mm and the auto-indexs can be expanded to four.

* The concentrated lubricating mechanism can lubricate directly the various points to reduce work load and pair friction, thus improving its service life.
